MICROFIT MFHR56941 Replaces the Main Filter MF0426666

MICROFIT MFHR56941
Representative product image Product image feedback

MICROFIT® UltraGen III MFHR56941 Replaces the Main Filter MF0426666

MFHR56941
MICROFIT
Main Filter MF0426666
Description

The MICROFIT® UltraGen III MFHR56941 is the MICROFIT® approved replacement to the Main Filter MF0426666. Engineered and manufactured in Great Britain the MFHR56941

Brand: MICROFIT
Price Matched
€83,95
0.51 kg
8421.99.90
United Kingdom
0.23 kg
8421.99.90
Italy
0.3 kg
8421.99.90
France
Shipping Terms

Description

The MICROFIT® UltraGen III MFHR56941 is the MICROFIT® approved replacement to the Main Filter MF0426666. Engineered and manufactured in Great Britain the MFHR56941

Specification

StyleReturn Filter
Efficiency 120µ @ β200
Efficiency 222µ @ β1000
Outer Diameter 70 mm
Inner Diameter 33.5 mm
Length 122 mm
MediaGlass Fiber
Flow DirectionOUT-IN
Δ Collapse Pressure 10 BAR
Seal MaterialViton
Temperature Range -25 - +120°C

Approved Product

Find out more
Default Brand Logo

Same Fit-Form & Function

As the Genuine Main Filter MF0426666

ISO Icon

Inspected to ISO 9001:2015

See Our Certification
Returns Icon

Free 45-Day Returns

Return Policy
Warranty Icon

1 Year Manufacturer Warranty

Our Warranty
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
20µ @ β200
Efficiency 2 22µ @ β1000
Style Return Filter
Outer Diameter 70 mm
Inner Diameter 33.5 mm
Length 122 mm
Media Type Glass Fiber
Flow Direction OUT-IN
Thread
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

Collapse Pressure 10 BAR
Seal Viton
Temperature Range -25 - +120°C
