Specification

StyleSpecial Filter
Efficiency 110µ
Outer Diameter 44.0 mm
Inner Diameter 22.2 mm
Length 173.0 mm
Bypass Pressure 1.0 BAR
MediaSynthetic Polyester
Flow DirectionIN-OUT
Seal MaterialViton
Temperature Range -30 - +100°C

FilterFinder Approved Product

We Guarantee This FilterFinder FF208181B Is

  • The Same Fit, Form & Function as the Original CASE 2950569.
  • Fully Inspected in Accordance with ISO 9001:2015.

What This Means For You

  • Simple No Quibble 45 Day Returns.
  • 1 Year Manufacturer Warranty.
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
10µ
Efficiency 2
Style Special Filter
Outer Diameter 44.0 mm
Inner Diameter 22.2 mm
Length 173.0 mm
Media Type Synthetic Polyester
Flow Direction IN-OUT
Thread
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

1.0 BAR
Collapse Pressure
Seal Viton
Temperature Range -30 - +100°C
